Fuse Block: Locations
- Make
- GMC
- Model
- Savana 3500
- Engine
- V8-4.8L
- Year
- 2009
- Section
- Fuse Block › Locations
Power and Ground DistributionLocations
Fuse Block: Locations
Front of Vehicle/Engine Compartment Component Views
Engine Compartment
1 - Vacuum Pump (6.6L)
2 - Battery
3 - Transmission Control Module (TCM)
4 - Blower Motor Resistor
5 - Blower Motor
6 - Brake Fluid Level Switch (Heavy Duty)
7 - Engine Control Module (ECM)
8 - Fuse Block - Underhood
