18. Remove the camshaft sprocket.
1) Hold the portion (A) of the camshaft with a hexagonal wrench, and remove the bolt (C) with a wrench (B) and remove the camshaft sprocket.
CAUTION: Be careful not to damage the cylinder head and valve lifter with the wrench.
INSTALLATION
1. Install the camshaft sprocket and tighten the bolt to the specified torque.
1) Temporarily install the camshaft sprocket bolt (C).
2) Hold the portion (A) of the camshaft with a hexagonal wrench, and tighten the bolt (C) with a wrench (B).
