ADDITIONAL HEATER LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| D006 | Front/rear coupling | |
| D008 | Air conditioning-heater front coupling | |
| D021 | Dashboard/air conditioning-heater coupling | |
| D097 | Short circuit coupling | |
| D190 | ||
| H001 | Ignition switch | |
| I050 | Inertia switch | 1040A |
| M001 | Body computer | |
| M063 | Luggage compartment control unit (NVB) | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M070 | Climate control sytem control unit | 5040D |
| M075 | Additional heater control unit | |
| N040 | 1040A | |
| N044 | ||
| P135 | Additional heater aerial |
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C010 | Left front earth | |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| D006 | Front/rear coupling | |
| D008 | Air conditioning-heater front coupling | |
| D021 | Dashboard/air conditioning-heater coupling | |
| D097 | Short circuit coupling | |
| D190 | ||
| H001 | Ignition switch | |
| I050 | Inertia switch | 1040A |
| M001 | Body computer | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M070 | Climate control sytem control unit | 5040D |
| M075 | Additional heater control unit | |
| N040 | 1040A | |
| N044 | ||
| P135 | Additional heater aerial |
