Circuit Qualifiers

Certain abbreviations are used throughout the Electrical Troubleshooting Manual as circuit qualifiers. The following list explains all abbreviations used as qualifiers in the Circuit Diagrams.

ABS Anti-Lock Braking System

LHD Lefthand Drive

RHD Righthand Drive

LWB Long Wheel Base

SWB Short Wheel Base

NAS North American Countries

MFI-V8 Multiport Fuel Injection (MFI1-V8)

MFI-T16 Multiport Fuel Injection (MFI-T16)

300 Tdi Tdi Diesel

300 Tdi with Tdi Diesel with Exhaust Gas EGR Recirculation (EGR)

300 Tdi without Tdi Diesel without Exhaust EGR Gas Recirculation (EGR)

300 Tdi with Tdi Diesel with Electronic

EDC Diesel Control (EDC)

300 Tdi without Tdi Diesel without Electron-

EDC ic Diesel Control (EDC) (applies to Tdi Diesels with and without EGR)

SFI-V8 Sequential Multiport Fuel Injection (SFI-V8)

A/C Air Conditioning

BBUS Battery Backed Up Alarm Sounder (2272)

Switch Positions

Certain abbreviations are used throughout the Electrical Troubleshooting Manual as Switch Position notes. The following list explains all abbreviations used as Switch Position notes in the Circuit Diagrams.

< 100 Less than 100

> 100° More than 100°
