Freelander Brake System Operation - Page 308
BRAKES
70-20
DESCRIPTION AND OPERATION
ABS System Failure Warning Lamps
Operating Condition
Brake/ EBD
(Red)
ABS (Amber)
ETC (Amber)
HDC Fault
(Amber)
HDC Information
(Green)
Bulb check (ABS warning
lamp only flashes off if
there are no faults stored
in the ABS ECU):
Up To 2002 MY
On for 1.7
seconds
On for 1.7
seconds, off for
0.5 second, on
until vehicle
speed >7 km/h
then off
On for 1.7
seconds
On for 1.7
seconds
On for 1.7 seconds
From 2002 MY
On for 2.7
seconds
On for 1.7
seconds, off for
0.5 second, on
for 0.5 second
then off
On for 2.7
seconds
On for 2.7
seconds
On for 2.7 seconds
Normal operation (no
faults detected)
Off
Off (after lamp
check)
Off
Off
Off
Hand brake on
On
Off
Off
Off
Off
Low brake fluid
On
Off
Off
Off
Off
ABS failure
Off
On
On
On
Off
ETC failure
Off
Off
On
On
Off
ABS and EBD failure
On
On
On
On
Off
ABS ECU not connected
On
On
On
On
Off
Diagnostic mode
On
On
On
On
On
ETC disabled mode
Off
Off
On
On
Off
HDC selected, conditions
not met for HDC operation
Off
Off
Off
Off
Flashes at 2Hz
HDC selected, HDC is
available and vehicle
ready for descent
Off
Off
Off
Off
On
HDC failure
Off
Off
Off
On
Off
Brakes overheated
Off
Off
Flashes at 2Hz
Flashes at 2Hz (if
HDC selected)
-
