Freelander Service Procedures
CHARGING AND STARTING
REPAIRS 86-1-13
Carrier - battery
$% 86.15.11
Remove
1. Remove battery.
2. Models with cruise control: Disconnect
multiplug and hose from cruise control vacuum
pump if fitted.
3. Release harness clips from battery carrier.
4. Remove 4 bolts and remove battery carrier.
5. Models with cruise control: Remove cruise
control vacuum pump and mountings from
battery carrier if fitted.
Refit
1. Models with cruise control: Fit mountings
and cruise control vacuum pump to battery
carrier if fitted.
2. Fit battery carrier and tighten bolts to 10 Nm
(7.5 lbf.ft).
3. Secure harness clips to battery carrier.
4. Models with cruise control: Connect
multiplug and hose to cruise control vacuum
pump if fitted.
5. Fit battery.
