Freelander Service Procedures
STEERING
REPAIRS
57-19
Refit
1. Position cable, align to heater and steering
column bracket and secure in retaining clips.
2. Align key interlock cable to column lock and
tighten union to 4 Nm (3 lbf.ft).
3. Fit height adjuster clamp bolt and tighten nut to
10 Nm (7.5 lbf.ft). Ensure bolt and plastic stop
are correctly located in slot in column bracket.
4. Fit height adjuster lever and tighten bolt 12 Nm
(9 lbf.ft). Ensure lever is in the fully up position
before tightening bolt. Hold clamp bolt nut to
prevent nut rotation.
5. Connect cable to interlock mechanism.
6. Check key interlock cable adjustment.
7. Fit steering column nacelle.
8. Fit front console.
REPAIRS, Console - front - up to 04MY.
9. Connect battery earth lead.
Column assembly - inner & outer
$% 57.41.01
Remove
1. Disconnect battery earth lead.
2. Remove steering column multi purpose switch.
combined direction indicator/headlight/
horn.
3. Disconnect multiplugs from ignition switch and
passive coil.
4. Remove 2 screws securing steering column
aperture trim and remove trim.
