LR3/Disco 3
6 .
Evenly and progressively, tighten the outer bolts, nuts and Torx screws to 10 Nm (7 lb.ft).
7 .
Tighten the 2 rear bolts to 43 Nm (32 lb.ft).
8 .
Using the special tool, tighten the 8 cylinder block cradle set screws.
Tighten the set screws in the sequence shown to 7 Nm (5 lb.ft).
9 .
NOTE :
The sealing washers are fitted to the silver coloured bolts. The silver coloured bolts are fitted in the 2
forward holes.
Install the 8 cylinder block cradle bolts and tighten in 2 stages.
Install 2 new sealing washers.
Tighten the bolts in sequence to 15 Nm (11 lb.ft).
Tighten the bolts in sequence to 34 Nm (25 lb.ft).
10 .
NOTE :
Lubricate new seals with clean engine oil.
Install the oil temperature sensor.
Clean the component mating faces.
Install a new O-ring seal.
Tighten the oil temperature sensor to 20 Nm (15 lb.ft).
Connect the electrical connector.
11 .
NOTE :
Lubricate new seals with clean engine oil.
Install the oil strainer pick-up assembly.
Clean the components.
