Alignment: Specifications
Front Suspension

Toe-in

Standard value .......................................................................................................................................................................  1 ± 2 mm (0.04 ± 0.09 inch)

STEERING ANGLE

Standard value:

CAMBER, CASTER AND KINGPIN INCLINATION

Standard value:

Camber .................................................................................................................................................  0°20' ± 0°30' (Left/right deviation within 30')
Caster ....................................................................................................................................................  2°35' ± 0°30' (Left/right deviation within 30')
Kingpin inclination ................................................................................................................................................................................  12°45' ± 1°30'
