Windshield Washer Pump: Locations
Harness Routing Views
Forward Lamps Harness
1 - Ground Chassis Fender - G104 (Jumpstart Negative post)
2 - Horn - Left Connector - B9
3 - Headlamp Assembly - Left Connector - E121
4 - Inflatable Restraint Front Sensor (LF) Connector - B47
5 - FWD Lamps Harness to Hood Ajar Harness - X105
6 - Windshield Washer Fluid Pump Connector - M19
7 - Ambient Air Temperature Sensor Connector - B23 (Electronic Climate Control Only)
8 - Forward Lamp Harness to Cooling Fan Harness Connector - X162
9 - Forward Lamps to Body Front Wiring Connector 1 - X107
10 - Inflatable Restraint Front Sensor (RF) Connector - B47
11 - Horn - Right Connector - B9
12 - Headlamp Assembly - Right Connector - E121
13 - Fuse Block - Underhood - X124
