Rover Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition10 · Differential – manual gearbox
10 · Transmission

Final Driven Gear Replacement

Make
Rover
Model
600 Rover 600 Repair Manual - Volumes 1 and 2 - 2nd Edition
Section
Repairs › Final Driven Gear Replacement
Differential – manual gearboxFinal Driven Gear Replacement
Diagram showing installation of tapered roller bearing onto differential carrier using a tool

A Differential Carrier

B Tapered Roller Bearing

  1. Install new tapered roller bearings using the special tool as shown.

Note: Drive the tapered roller bearings on until they bottom against the differential carrier.

Final Driven Gear Replacement

Diagram showing final driven gear and bolt being removed from differential carrier

A Final Driven Gear

B Bolt

  1. Remove the bolts in a crisscross pattern in several steps, then remove the final driven gear.
  2. Inspect teeth for wear and damage.
  3. Install the final driven gear.

Note: Final driven gear bolts have left-hand threads.
