Cruise ControlDiagnostic Aids · page 82 of 100
View of the female half of the connector with male terminals.
3. Use the J 38125-215 tool to release the terminals by inserting the tool into the terminal release cavity. See the release tool cross reference in the
Reference Guide of theJ-38125 to ensure that the correct release tool is used.
View of the female half of the connector with male terminals.
