Honing
dimensions

Main journal
ø

Conrod journal
ø

Basic
dimension

- 0.022
54.00
- 0.042

- 0.022
47.80
- 0.042

1st undersize

- 0.022
53.75
- 0.042

- 0.022
47.55
- 0.042

2nd undersize

- 0.022
53.50
- 0.042

- 0.022
47.30
- 0.042

3rd undersize

- 0.022
53.25
- 0.042

- 0.022
47.05
- 0.042
