Bumpers: Specifications
- Make
- Aston Martin
- Model
- DB9 Factory Workshop Manual
- Year
- Issue 2, 2005
- Section
- Bumpers › Specifications
01 Body systemSpecifications · page 1 of 2
Specifications
| Torque Figures | ||
|---|---|---|
| Description | Nm | lb. / ft. |
| Bumper to bumper bracket | 2-3 | 1.5-2.5 |
Maintenance
| Repair Operation Time (ROT) | |
|---|---|
| Item | Code |
| Bumper Remove / Install | 01.19.BB |
Removal
- Remove the light clusters.
- Open the boot and remove the trim from around the light cluster mounts.
- Release and remove nuts (x3).
- Withdraw the rear light cluster unit. Disconnect the wiring harness plug.
- Remove the bumper tag screw.
