Throttles and Inlet Manifolds (page 6 of 6)
- Make
- Aston Martin
- Model
- DB9 Factory Workshop Manual
- Year
- Issue 2, 2005
- Section
- Torque Figures
20 Appendix and glossaryThrottles and Inlet Manifolds · page 6 of 6
Throttles and Inlet Manifolds (page 6 of 6) – diagram from the 20 Appendix and glossary chapter of the Aston Martin DB9 Factory Workshop Manual (Issue 2, 2005) factory manual.
