A001 battery
- Make
- Fiat
- Model
- Croma Factory Service Manual
- Year
- 2005–2010
- Section
- Starting - recharging › A001 battery
Connectors and pin-outsA001 battery
A001 BATTERY
A001B – Battery negative
| Wiring | Colour |
|---|---|
| See 40 BATTERY NEGATIVE | _ |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 16 | N | X | See C003 BATTERY EARTH ON BODYSHELL | 1 |
| See C002 BATTERY EARTH ON ENGINE | 1 | ||||
