INSTRUMENT LIGHTING - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
H1	Ignition switch	Op. 5520A IGNITION SWITCH
H5	Stalk unit	Op. 5550A STALK UNIT
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
H1	Ignition switch	Op. 5520A IGNITION SWITCH
H5	Stalk unit	Op. 5550A STALK UNIT
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H5	STEERING COLUMN SWITCH UNIT	Op. 5550A STALK UNIT
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
