19 · Electrical

Courtesy lights - wiring diagram

Make: Fiat
Model: Doblò Factory Service Manual
Year: 2000–2010
Section: Interior lighting › Courtesy lights - wiring diagram

‹ Prev Courtesy lights - functional description Next › Courtesy lights - location of components

Wiring diagrams and electrical functionsCourtesy lights - wiring diagram

COURTESY LIGHTS - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D196	Right sliding side door coupling
D197	Right sliding side door coupling
D35	Rear left door connection
D36	Rear right door connection
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
G10	Front courtesy light	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	Rear (centre courtesy light)
G20	Rear (centre courtesy light)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
I16	Switch on left front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I17	Switch on right front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I21	Switch on rear door	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03 · 7 seater

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D196	Right sliding side door coupling
D197	Right sliding side door coupling
D35	Rear left door connection
D36	Rear right door connection
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
G10	Front courtesy light	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	Rear (centre courtesy light)
G20	Rear (centre courtesy light)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
I16	Switch on left front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I17	Switch on right front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I21	Switch on rear door	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C30	Left rear earth
D196	Right sliding side door coupling
D197	Right sliding side door coupling
D35	Rear left door connection
D36	Rear right door connection
D85	Tailgate rear seal/
D85	Tailgate/ rear coupling
G10	Front courtesy light	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	Rear (centre courtesy light)
G20	Rear (centre courtesy light)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
I16	Switch on left front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I17	Switch on right front door	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I21	Switch on rear door	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M1	Body computer
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D085	TAILGATE/REAR SEAL
G010	FRONT COURTESY LIGHT	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	REAR COURTESY LIGHT (CENTRE)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I016	SWITCH ON LEFT FRONT DOOR.	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I17	SWITCH ON RIGHT FRONT DOOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005, Sliding door

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D30	REAR/DRIVER''S FRONT DOOR COUPLING
D31	REAR/PASSENGER FRONT DOOR COUPLING
D085	TAILGATE/REAR SEAL
D196	LEFT SLIDING SIDE DOOR COUPLING
D197	RIGHT SLIDING SIDE DOOR COUPLING
G010	FRONT COURTESY LIGHT	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	REAR COURTESY LIGHT (CENTRE)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N50	DRIVER''S FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	PASSENGER FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Doblò trim level, MY 2005

Components

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D30	REAR/DRIVER''S FRONT DOOR COUPLING
D31	REAR/PASSENGER FRONT DOOR COUPLING
D42	COURTESY LIGHT COUPLING
D085	TAILGATE/REAR SEAL
D196	LEFT SLIDING SIDE DOOR COUPLING
D197	RIGHT SLIDING SIDE DOOR COUPLING
G010	FRONT COURTESY LIGHT	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	REAR COURTESY LIGHT (CENTRE)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N50	DRIVER''S FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	PASSENGER FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Long wheelbase version, MY 2005

Components

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D085	TAILGATE/REAR SEAL
D097	SHORT CIRCUITING COUPLING
G010	FRONT COURTESY LIGHT	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	REAR COURTESY LIGHT (CENTRE)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G25	LEFT REAR COURTESY LIGHT
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I016	SWITCH ON LEFT FRONT DOOR.	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I17	SWITCH ON RIGHT FRONT DOOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Long wheelbase version, MY 2005, Sliding door

Components

1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005, Sliding door

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
C030	LEFT REAR EARTH
D30	REAR/DRIVER''S FRONT DOOR COUPLING
D31	REAR/PASSENGER FRONT DOOR COUPLING
D085	TAILGATE/REAR SEAL
D097	SHORT CIRCUITING COUPLING
D196	LEFT SLIDING SIDE DOOR COUPLING
D197	RIGHT SLIDING SIDE DOOR COUPLING
G010	FRONT COURTESY LIGHT	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G20	REAR COURTESY LIGHT (CENTRE)	Op. 7040E INTERIOR COURTESY LIGHT SYSTEM
G25	LEFT REAR COURTESY LIGHT
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
I11	BOOT OPENING SWITCH	Op. 7015B TAILGATE CLOSING/OPENING DEVICES
I21	SWITCH ON REAR DOOR	Op. 7020P REAR SWING DOOR CENTRAL LOCKING
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
N50	DRIVER''S FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
N51	PASSENGER FRONT DOOR LOCK GEARED MOTOR	Op. 7005N FRONT DOOR CENTRAL LOCKING SYSTEM
