D085 TAILGATE/REAR SEAL
D085A – Left swing door
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See F040 ADDITIONAL REAR LIGHT ('THIRD BRAKE LIGHT) 1 2 0,35 BL See F050 LEFT NUMBER PLATE LIGHT 2 3 1,5 H See N052 REAR DOOR LOCK GEARED MOTOR 1 4 0,5 VN See N016 REAR WINDOW WIPER MOTOR 1 5 0,75 BG See N016 REAR WINDOW WIPER MOTOR 3 6 1,5 G See N052 REAR DOOR LOCK GEARED MOTOR 2 7 0,35 BL See F051 RIGHT NUMBER PLATE LIGHT 2 8 0,35 NR See I021 SWITCH ON REAR DOOR 3 9 0,35 RV See I021 SWITCH ON REAR DOOR 1 10 2,5 N X See I021 SWITCH ON REAR DOOR 2 See N016 REAR WINDOW WIPER MOTOR 2 See F050 LEFT NUMBER PLATE LIGHT 2 See F051 RIGHT NUMBER PLATE LIGHT 1 See F040 ADDITIONAL REAR LIGHT ('THIRD BRAKE LIGHT) 2 11 2,5 N See P054A LEFT HEATED REAR WINDSCREEN (LEFT SWING DOOR) 1 12 2,5 MB See P054B LEFT HEATED REAR WINDSCREEN (LEFT SWING DOOR) 1
D085A – Tailgate
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See F040 ADDITIONAL REAR LIGHT ('THIRD BRAKE LIGHT) 1 2 0,35 BL See F050 LEFT NUMBER PLATE LIGHT 2 3 1,5 H See N057 BOOT LOCK GEARED MOTOR 1 4 0,5 VN See N016 REAR WINDOW WIPER MOTOR 1 5 0,75 BG See N016 REAR WINDOW WIPER MOTOR 3 6 1,5 G See N057 BOOT LOCK GEARED MOTOR 2 7 0,35 BL See F051 RIGHT NUMBER PLATE LIGHT 2 8 0,35 NR X See I011 BOOT OPENING SWITCH 1 See D085A TAILGATE REAR SEAL/ (LEFT SWING DOOR) 9 9 0,35 RV X See I011 BOOT OPENING SWITCH 1 See D085A TAILGATE REAR SEAL/ (LEFT SWING DOOR) 8 10 2,5 N X See N016 REAR WINDOW WIPER MOTOR 2 See F040 ADDITIONAL REAR LIGHT ('THIRD BRAKE LIGHT) 2 See I011 BOOT OPENING SWITCH 2 See F050 LEFT NUMBER PLATE LIGHT 1 See F051 RIGHT NUMBER PLATE LIGHT 1 11 2,5 N See P054A LEFT HEATED REAR WINDSCREEN (LEFT SWING DOOR) 1 12 2,5 MB See P054B LEFT HEATED REAR WINDSCREEN (LEFT SWING DOOR) 1
D085A – Rear
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Long wheelbase version, MY 2005, Sliding door
Wiring Colour See 25 REAR BIANCO
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 5 2 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 26 3 1,5 H See D097A SHORT CIRCUITING COUPLING (REAR) 6 4 0,5 VN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 9 5 0,75 BG See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 20 6 1,5 G See D097C SHORT CIRCUITING COUPLING (REAR) 6 7 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 25 8 0,35 NV X See M001A BODY COMPUTER (REAR) 26 See D097A SHORT CIRCUITING COUPLING (REAR) 1 See M001A BODY COMPUTER (REAR) 16 See D196A RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 1 See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR ) 3 See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 3 See G020 REAR (CENTRE) COURTESY LIGHT 3 See G025 LEFT REAR COURTESY LIGHT 3 9 0,35 RV See M001A BODY COMPUTER (REAR) 36 10 2,5 N See C030 LEFT REAR EARTH 10 11 2,5 N See C030 LEFT REAR EARTH 9 12 2,5 MB X See D085B TAILGATE REAR SEAL/ (RIGHT SWING DOOR) A See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 15
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Long wheelbase version, MY 2005
Wiring Colour See 25 REAR BIANCO
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 5 2 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 26 3 1,5 H See D097A SHORT CIRCUITING COUPLING (REAR) 6 4 0,5 VN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 9 5 0,75 BG See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 20 6 1,5 G See D097C SHORT CIRCUITING COUPLING (REAR) 6 7 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 25 8 0,35 NR X See G020 REAR (CENTRE) COURTESY LIGHT 3 See G025 LEFT REAR COURTESY LIGHT 3 9 0,35 RV See M001A BODY COMPUTER (REAR) 36 10 2,5 N See C030 LEFT REAR EARTH 10 11 2,5 N See C030 LEFT REAR EARTH 9 12 2,5 MB X See D085B TAILGATE REAR SEAL/ (RIGHT SWING DOOR) A See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 15
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Doblò trim level, MY 2005
Wiring Colour See 25 REAR BIANCO
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 5 2 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 26 3 1,5 H See D097A SHORT CIRCUITING COUPLING (REAR) 6 4 0,5 VN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 9 5 0,75 BG See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 20 6 1,5 G See D097C SHORT CIRCUITING COUPLING (REAR) 6 7 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 25 8 0,35 NV X See M001A BODY COMPUTER (REAR) 26 See D097A SHORT CIRCUITING COUPLING (REAR) 1 See M001A BODY COMPUTER (REAR) 16 See D196A RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 1 See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR ) 3 See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 3 See D042 COURTESY LIGHT COUPLING 3 See G040 BOOT COURTESY LIGHT 1 9 0,35 RV See M001A BODY COMPUTER (REAR) 36 10 2,5 N See C030 LEFT REAR EARTH 10 11 2,5 N See C030 LEFT REAR EARTH 9 12 2,5 MB X See D085B TAILGATE REAR SEAL/ (RIGHT SWING DOOR) A See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 15
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005, Sliding door
Wiring Colour See 25 REAR BIANCO
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 5 2 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 26 3 1,5 H See D097A SHORT CIRCUITING COUPLING (REAR) 6 4 0,5 VN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 9 5 0,75 BG See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 20 6 1,5 G See D097C SHORT CIRCUITING COUPLING (REAR) 6 7 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 25 8 0,35 NV X See M001A BODY COMPUTER (REAR) 26 See D097A SHORT CIRCUITING COUPLING (REAR) 1 See M001A BODY COMPUTER (REAR) 16 See D196A RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 1 See D197B RIGHT SLIDING SIDE DOOR COUPLING ( REAR RIGHT DOOR ) 3 See D196B RIGHT SLIDING SIDE DOOR COUPLING ( REAR LEFT DOOR ) 3 See G020 REAR (CENTRE) COURTESY LIGHT 3 9 0,35 RV See M001A BODY COMPUTER (REAR) 36 10 2,5 N See C030 LEFT REAR EARTH 10 11 2,5 N See C030 LEFT REAR EARTH 9 12 2,5 MB X See D085B TAILGATE REAR SEAL/ (RIGHT SWING DOOR) A See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 15
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · Cargo trim level, MY 2005
Wiring Colour See 25 REAR BIANCO
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 5 2 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 26 3 1,5 H See D097A SHORT CIRCUITING COUPLING (REAR) 6 4 0,5 VN See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 9 5 0,75 BG See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 20 6 1,5 G See D097C SHORT CIRCUITING COUPLING (REAR) 6 7 0,35 BL See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 25 8 0,35 NR See G020 REAR (CENTRE) COURTESY LIGHT 3 9 0,35 RV See M001A BODY COMPUTER (REAR) 36 10 2,5 N See C030 LEFT REAR EARTH 10 11 2,5 N See C030 LEFT REAR EARTH 9 12 2,5 MB X See D085B TAILGATE REAR SEAL/ (RIGHT SWING DOOR) A See B002D JUNCTION UNIT UNDER DASHBOARD (REAR) 15
D085B – Right swing door
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005
D085B – Rear
1.4 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V · from 12/03 · MY 2005
Wiring Colour See 25 REAR NERO
D85A – Left tailgate
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 1 2 0,35 BL See F050 LEFT NUMBER PLATE LIGHT 2 3 1,5 H See N52 REAR DOOR LOCK GEARED MOTOR ( LEFT TAILGATE ) 2 4 0,5 VN See N016 REAR WINDOW WIPER MOTOR 1 5 0,75 BG See N016 REAR WINDOW WIPER MOTOR 3 6 1,5 G See N52 REAR DOOR LOCK GEARED MOTOR ( LEFT TAILGATE ) 1 7 0,35 BL See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 2 8 0,35 NR x See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 1 See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE ) 9 9 0,35 RV x See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 1 See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE ) 8 10 2,5 NV x See N016 REAR WINDOW WIPER MOTOR 2 x See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 2 x See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 2 x See F050 LEFT NUMBER PLATE LIGHT 1 x See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 1 11 2,5 N See P054 LEFT HEATED REAR WINDSCREEN 1 12 2,5 MB See P054 LEFT HEATED REAR WINDSCREEN 2
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 1 2 0,35 BL See F050 LEFT NUMBER PLATE LIGHT 2 3 1,5 H See N52 REAR DOOR LOCK GEARED MOTOR ( LEFT TAILGATE ) 2 4 0,5 VN See N016 REAR WINDOW WIPER MOTOR 1 5 0,75 BG See N016 REAR WINDOW WIPER MOTOR 3 6 1,5 G See N52 REAR DOOR LOCK GEARED MOTOR ( LEFT TAILGATE ) 1 7 0,35 BL See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 2 8 0,35 NR See I21 SWITCH ON REAR DOOR ( LEFT TAILGATE ) 3 9 0,35 RV See I21 SWITCH ON REAR DOOR ( LEFT TAILGATE ) 1 10 2,5 N x See N016 REAR WINDOW WIPER MOTOR 2 x See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 2 x See I21 SWITCH ON REAR DOOR ( LEFT TAILGATE ) 2 x See F050 LEFT NUMBER PLATE LIGHT 1 x See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 1 11 2,5 N See P054 LEFT HEATED REAR WINDSCREEN 1 12 2,5 MB See P054 LEFT HEATED REAR WINDSCREEN 2
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 1 2 0,35 BL See F050 LEFT NUMBER PLATE LIGHT 2 3 1,5 H See N57 BOOT LOCK GEARMOTOR ( LEFT TAILGATE ) 2 4 0,5 VN See N016 REAR WINDOW WIPER MOTOR 1 5 0,75 BG See N016 REAR WINDOW WIPER MOTOR 3 6 1,5 G See N57 BOOT LOCK GEARMOTOR ( LEFT TAILGATE ) 1 7 0,35 BL See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 2 8 0,35 NR X See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE ) 9 See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 1 9 0,35 RV X See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE ) 8 See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 1 10 2,5 N X See N016 REAR WINDOW WIPER MOTOR 2 See F40 ADDITIONAL (THIRD BRAKE LIGHT) ( LEFT TAILGATE ) 2 See I11 BOOT OPENING SWITCH ( LEFT TAILGATE ) 2 See F050 LEFT NUMBER PLATE LIGHT 1 See D85A TAILGATE REAR SEAL/ ( LEFT TAILGATE ) 10 See F51 RIGHT NUMBER PLATE LIGHT ( LEFT TAILGATE ) 1 11 2,5 N 1 12 2,5 MB 1
D85A – Rear
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL
Wiring Colour See 25 REAR bianco
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 5 2 0,35 BL See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 26 3 1,5 H See D97A SHORT CIRCUITING COUPLING ( REAR ) 6 4 0,5 VN See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 9 5 0,75 BG See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 20 6 1,5 G See D97C SHORT CIRCUITING COUPLING ( REAR ) 28 7 0,35 BL See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 25 8 0,35 NR See G20 REAR (CENTRE COURTESY LIGHT) ( REAR ) 3 9 0,35 RV See M1A BODY COMPUTER ( REAR ) 36 10 2,5 N See C30 LEFT REAR EARTH ( REAR ) 10 11 2,5 N See C30 LEFT REAR EARTH ( REAR ) 9 12 2,5 MB x See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 15 x See D85B TAILGATE REAR SEAL/ ( RIGHT DOOR )
Wiring Colour See 25 REAR bianco
Pin Cable Destination Sec. Colour Node Connect. Pin 1 0,5 CN See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 5 2 0,35 BL See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 26 3 1,5 H See D97A SHORT CIRCUITING COUPLING ( REAR ) 6 4 0,5 VN See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 9 5 0,75 BG See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 20 6 1,5 G See D97C SHORT CIRCUITING COUPLING ( REAR ) 28 7 0,35 BL See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 25 8 0,35 NR See G040 BOOT COURTESY LIGHT 2 9 0,35 RV See M1A BODY COMPUTER ( REAR ) 36 10 2,5 N See C30 LEFT REAR EARTH ( REAR ) 10 11 2,5 N See C30 LEFT REAR EARTH ( REAR ) 9 12 2,5 MB x See B2D JUNCTION UNIT UNDER DASHBOARD ( REAR ) 15 x See D85B TAILGATE REAR SEAL/ ( RIGHT DOOR )
D85B – Right door
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL
D85B – Rear
1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL
Wiring Colour See 25 REAR nero
