D62 side bag coupling

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Intermediate couplings › D62 side bag coupling

Connectors and pin-outsD62 side bag coupling

D62 SIDE BAG COUPLING

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL

Wiring	Colour
See 25 REAR	nero

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	ZG		See M60B AIR BAG CONTROL UNIT ( REAR )	18
2	0,5	R		See M60B AIR BAG CONTROL UNIT ( REAR )	17
3	0,5	N	x	See D63 REAR PASSENGER SIDE- BAG COUPLING/ ( SIDE BAG )	3
			x	See C053 SIDE BAG + HEAD BAG EARTH	1

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · AIR BAG

Wiring	Colour
See 62 SIDE BAG

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	0,5	ZG		See Q30 DRIVER'S SIDE BAG ( SIDE BAG )	1
2	0,5	R		See Q30 DRIVER'S SIDE BAG ( SIDE BAG )	2
3	0,5	N		See Q30 DRIVER'S SIDE BAG ( SIDE BAG )	3
