HORNS - Wiring diagram

Make

Fiat

Model

Panda Factory Service Manual

Year

2003–2012

Section

Electrically activated devices › HORNS - Wiring diagram

Wiring diagrams and electrical functionsHORNS - Wiring diagram

HORNS - Wiring diagram

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit	5505C
B1	engine compartment junction unit	5505C
C11	Right front earth
C20	Passenger side dashboard earth
D110	Clock spring and steering wheel controls coupling
M1	Body computer	5505A
P11	Low-tone horn	5550B

20 Electrical
