SUN ROOF - Wiring diagram
- Make
- Fiat
- Model
- Panda Factory Service Manual
- Year
- 2003–2012
- Section
- Electrically activated devices › SUN ROOF - Wiring diagram
Wiring diagrams and electrical functionsSUN ROOF - Wiring diagram
SUN ROOF - Wiring diagram
Wiring diagram
COMPONENTS
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | Engine compartment junction unit | 5505C |
| B1 | engine compartment junction unit | 5505C |
| B2 | Junction unit under dashboard | 5505C |
| C20 | Passenger side dashboard earth | |
| D1 | Front dashboard coupling | |
| D1 | Front / dashboard coupling | |
| D1 | front / dashboard coupling | |
| D20 | /Rear dashboard coupling | |
| D20 | Rear dashboard coupling | |
| D97 | Short circuiting coupling | |
| H1 | Ignition switch | 5520A |
| M95 | Sun roof control unit |
