H37 Gear controls

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Manual electric controls › H37 Gear controls

Connectors and pin-outsH37 Gear controls

H37 Gear controls

2.4 20v · Smart gearbox

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N	X	D1	3
				M54B	65
2		H		M54A	26
3		B		M54B	68
4		M		M54B	67
5		S		M54B	74
