H5 Stalk unit

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Manual electric controls › H5 Stalk unit

Connectors and pin-outsH5 Stalk unit

H5 Stalk unit

H5A – Front

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2		CB		D97A	7
3		AN		M1A	1
5		BL		M1A	13
6		B		N15	3
7	2,5	N		C10	15
8	2,5	S		N15	5
9	2,5	RG		N15	1
10	2,5	ZG		N22	2
11		MB		B2A	10
12	2,5	H		N22	1

Openable rear window, S.W.

Wiring	Colour
12 FRONT	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
2		CB		D97A	7
3		AN		M1A	1
4		BR		D6	18
5		BL		M1A	13
6		B		N15	3
7	2,5	N		C10	15
8	2,5	S		N15	5
9	2,5	RG		N15	1
10	2,5	ZG		N22	2
11		MB		B2A	10
12	2,5	H		N22	1

H5B – Facia

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		CB		M1I	7
2		AL		M1G	33
3		AN		M1I	4
4		AV		M1I	2
5		BL		M1G	28
6		NZ		C15B	3

H5C – Facia

Wiring	Colour
20 FACIA	BIANCO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		AL		E50A	8
2	1	AV		B2G	17
3	1	AG		B2G	11
4		H		B2G	15
5		NZ		C15A	2
6		CB		M1G	30
