C10 Front left earth

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Earths › C10 Front left earth

Connectors and pin-outsC10 Front left earth

C10 Front left earth

Wiring	Colour
12 FRONT

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NZ		P90	3
3		NZ		K25	2
4		NZ		B1A	26
5	1,5	N		F10	14
7		N		F10	8
8		NZ		K64	2
9		N		F20	2
10	1,5	N		F10	13
12		N		J87	1
13		N		D79	9
				M54A
14		N		K99
15	2,5	N		H5A	7
16	2,5	N		N15	2
17		N		N47
23	1,5	N		D79	1
24		NZ		I31	4

21 General
