F10 Left headlamp

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Exterior lights › F10 Left headlamp

Connectors and pin-outsF10 Left headlamp

F10 Left headlamp

Wiring	Colour
12 FRONT	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		H		B2A	3
2	1	HN		B1A	4
3	1	W		B1A	25
4		BM		M1B	40
5		M		M1B	38
6		AG		D97C	8
7		CB		D97C	5
8		N		C10	7
9		L		M1A	10
				F11	9
10		AN		M1B	28
11		BL		D97B	3
12		AL		F11	12
13		N		C10	10
14		N		C10	5
