C15 Facia earth, driver's side

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Earths › C15 Facia earth, driver's side

Connectors and pin-outsC15 Facia earth, driver's side

C15 Facia earth, driver's side

C15A – Facia

Wiring	Colour
20 FACIA	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	1,5	N		B2H	10
2		NZ		H5C	5
3	2,5	N		P20A	8
5		NZ		G30	1
6		NZ		P20F	12
7		NZ		G35	2
8		NZ		D47	6
9		N		M89	9

C15B – Facia

Wiring	Colour
20 FACIA

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		M1I	8
3		NZ		H5B	6
4		NZ		H20	2
5		N		M1I	9

C15C – Rear

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		N		K62	2
2		N		G32	1
3	1,5	N		P50	3
4		N		G31	1
5		NZ		K85	2
6		N		D70	6

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		NZ		D31	10
2		N		D31	27
3	1,5	N		P50	3
4	1,5	N		I50	1
6		N		D70	6
