D47 Clock spring coupling

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Intermediate couplings › D47 Clock spring coupling

Connectors and pin-outsD47 Clock spring coupling

D47 Clock spring coupling

Wiring	Colour
Connectors	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1		AN		D1	8
3		NS		D97R	2
4		BS		D97R	7
5		LV		D97Q	8
6		NZ		C15A	8
7		NZ		D1	3
8		HB		D1	4
9		AR		M60A	19
10		BN		M60A	20
11		LN		M60A	24
12		BV		M60A	23
