Timing Belt: Diagrams (page 9 of 19)
- Make
- Hyundai
- Model
- Elantra
- Engine
- L4-2.0L
- Year
- 2004
- Section
- Timing Belt
MaintenanceDiagrams · page 9 of 19
10. Remove the 4 bolts (B) and timing belt upper cover (A).
11. Turn the crankshaft pulley, and align its groove with timing mark "T" of the timing belt cover.
12. Remove the crankshaft pulley bolt (B) and crankshaft pulley (A).
