TRANSFER BOX

OVERHAUL

17

DIFFERENTIAL UNIT

Service repair no - 41.20.13/01

Remove

1. Remove drive chain.

See this section.

2. Remove differential unit from rear output shaft.

Refit

1. Fit differential unit to rear output shaft.
2. Fit drive chain.

See this section.

DIFFERENTIAL BEARINGS

Service repair no - 41.20.17/01

Remove

1. Remove differential unit from transfer box.

See

this section.

2. Using a suitable puller, remove 2 bearings from

differential unit.

Refit

1. Ensure bearing and differential mating faces

are clean.

2. Press bearings onto differential unit.
3. Fit differential unit to transfer box.

See this

section.
