300Tdi Defender
04
GENERAL SPECIFICATION DATA
4
INFORMATION
Front axle
Type
Spiral bevel, enclosed constant velocity joints, fully
.................................................................................
floating shafts, 32
°
angularity of universal joint on full
lock
Ratio
3.54:1
.................................................................................
Propeller shafts
Type, front and rear
Tubular 51 mm dia.
..........................................................
Universal joints
Open type Hookes O3EHD
.................................................................
STEERING
Power steering box
Make/type
Adwest Varamatic - worm and roller box
........................................................................
Ratio
Variable: straight ahead 19.3:1 on lock 14.3:1
.................................................................................
Steering wheel turns, lock-to-lock
3.375
....................................
Steering pump
Make/type
Hobourn-Eaton series 500
........................................................................
Steering geometry
Steering wheel diameter
412 mm (16.22 in)
..................................................
Toe-out measurement
0 to 2 mm toe out
......................................................
Toe-out included angle
0
°
to 0
°
20’
.....................................................
Camber angle
0
°
*
..................................................................
Castor angle
3
°
*
.....................................................................
Swivel pin inclination static
7
°
*
...............................................
* Check with vehicle on level ground, in unladen
condition and five gallons of fuel. Rock the front of the
vehicle up and down to allow it to take up a normal
static position.
Turning circle between kerbs
90 models:
265/75 x 16 tyres
12,65 m (41.5 ft)
..............................................................
All other tyres
11,70 m (38.4 ft)
...................................................................
110 models:
750 x 16 tyres
13,41 m (44 ft)
..................................................................
130 models:
750 x 16 tyres
15,24 m (50 ft)
..................................................................
