Freelander System Description and Operation
AUTOMATIC GEARBOX - JATCO
44-4
DESCRIPTION AND OPERATION
JATCO Automatic Gearbox - Valve Block
and Solenoid Valves
1 Shift solenoid valve A
2 Reduction timing solenoid valve
3 Shift solenoid valve B
4 Shift solenoid valve C
5 2-4 brake duty solenoid valve
6 2-4 brake timing solenoid valve
7 Low clutch timing solenoid valve
8 Lock-up solenoid valve
9 Line pressure duty solenoid valve
