Freelander System Description and Operation
INSTRUMENTS
88-4
DESCRIPTION AND OPERATION
Instrument Pack Components -
Exploded View
1 Support bracket (2 off)
2 Warning lamp filter
3 RF receiver (Ref. only)
4 Panel illumination bulb (3 off)
5 Instrument pack housing assembly
6 Warning lamp filter
7 Instrument pack face plate
8 Instrument lens
