Freelander System Description and Operation
WINDOWS
DESCRIPTION AND OPERATION
86-6-5
1 Fusible link 4, engine compartment fusebox
2 Sunroof relay
3 Fusible link 3, engine compartment fusebox
4 Fuse 26, passenger compartment fusebox
5 Fuse 27, passenger compartment fusebox
6 Centre console RH rear window switch (5 door
only)
7 Door trim RH rear window switch (5 door only)
8 Isolator switch (5 door only)
9 RH rear window motor (5 door only)
10 LH rear window motor (5 door only)
11 Driver's window motor
12 Front passenger's window motor
13 Front passenger's window switch
14 Fuse 34, passenger compartment fusebox
15 Window lift relay
16 Ignition switch
17 Centre console LH rear window switch (5 door
only)
18 Fuse 8, passenger compartment fusebox
19 CCU
20 Door trim LH rear window switch (5 door only)
21 Window lift ECU
22 Driver's window switch
23 Fuse 33, passenger compartment fusebox
