Freelander Service Procedures
CHARGING AND STARTING
REPAIRS
86-1-5
Alternator - KV6
$% 86.10.02
Remove
1. Disconnect battery earth lead.
2. Remove top arm.
ENGINE - K SERIES KV6, REPAIRS,
Arm assembly - engine mounting RH.
3. Using a 3/8” square drive socket bar, raise
ancillary drive belt tensioner and release drive
belt from alternator pulley.
4. Release alternator battery lead terminal cover,
loosen terminal nut and disconnect lead from
terminal
5. Disconnect alternator multiplug.
6. Remove lower bolt and upper nut and bolt
securing alternator to front mounting plate.
7. Remove alternator.
Refit
1. Position alternator to front mounting plate.
2. Fit bolt and nut and bolt securing alternator to
front mounting plate and tighten to 45 Nm (33
lbf.ft).
3. Using a 3/8” square drive socket bar, raise
ancillary drive belt tensioner and fit drive belt to
pulleys.
4. Connect alternator multiplug.
5. Position battery cable to alternator, tighten nut
to 10 Nm (7.5 lbf.ft) and position terminal
cover.
6. Fit top arm.
ENGINE - K SERIES KV6, REPAIRS,
Arm assembly - engine mounting RH.
7. Connect battery earth lead.
