L322 Range Rover System Description and Operation
ENTERTAINMENT AND INFORMATION SYSTEMS
DESCRIPTION AND OPERATION 86-8-37
Radio Screen
l
Name of radio station
l
TP station (name of traffic programme station selected in background)
l
MFD Waveband selected
l
P3 positions the radio station (if programmed into the memory)
l
RDS (Radio Data System) is switched on, station names are displayed and the strongest frequency on which the
station can be picked up is searched for automatically
l
Date/time display
l
Radio screen display (showing radio stations that are available in the area)
l
Regional station function switched on.
If the radio is switched on and on-board computer functions appear on the monitor, the "Audio+OBC" function (on-
board computer) is switched on. Switch off the function (see the computer section).
To change the waveband the “AM/FM” button must be pressed. Each time the button is pressed the waveband
changes over as follows:
l
FM/FMD = VHF (very high frequency)
l
AM = MW (medium wave)/SW (short wave)/LW (long wave).
Manual Station Selection
It is also possible to manually tune onto a radio station by name or frequency. This is achieved as follows.
1 Select the desired waveband
2 Press the selection button to obtain the selection menu
3 Turn right-hand rotary control until "m Manual station choice" is marked
4 Press the direction arrows to tune the radio until the desired station is displayed.
To tune to the next station, press the tune button in the desired direction (up/down) the next available station will be
searched for. You can select in advance whether to jump to the next possible station or the next stored station, this
is achieved by the following process:
1 Press and hold in the “select key” until PRES ON or PRES OFF ("PRES" is short for PRE-SET) appears on the
monitor
2 PRES ON: Jumps to the next memorised station PRES OFF: Jumps to the next station.
Automatic Search
It is also possible to search and sample the available radio stations. With an Automatic search (SCAN) Stations with
a sufficiently strong signal are heard automatically for a short time, one after the other. This can be achieved as
follows:
1 Press the selection button to obtain the selection menu
2 Turn right-hand rotary control until "SCAN Station sample" is highlighted
3 Press the rotary controller to select this option and start the search
4 Pressing the “select” button stops the search at the tuned station.
B B C R 2
TMC
3 0 / 0 7 / 2 0 0 1
1 4 : 1 0
M o n d a y
B B C R 3
B B C R 4
C l a s s i c
R a d i o 1
F O X F M R e g 0
F O X F M R e g 0
B B C O x f d
H E A R T F M
> >
B B C R 4
9 2 . 7 M H z
T P - S t a t i o n
:
B B C W M
R E G
R E G
T P
T P
F M D
F M D
R D S
R D S
H4102
