Range Rover P38
64
REAR SUSPENSION
NEW RANGE ROVER
2
FAULT DIAGNOSIS
3. Symptom - Excessive body roll at rear of vehicle.
POSSIBLE CAUSE
REMEDY
1. Worn or leaking shock
absorber/s.
1. Renew shock absorber/s.
See Repair.
2. Worn radius arm bushes at
chassis mounting.
2. Renew radius arm bushes.
See Repair.
3. Loose radius arm fixings.
3. Check and tighten all relevant fixings.
4. Deflated air spring.
4. Check air system components for faults and air harness for leaks
etc.
See FRONT SUSPENSION, Repair.
Rectify or renew components where necessary.
5. Faulty valve block.
5. Refer to TestBook .
6. Damaged or broken chassis
and/or axle mounting brackets.
6. Vehicle should be recovered and not driven.
7. Failed or loose body mountings
giving excessive body
movement to chassis.
7. Tighten fixings or renew rubber body mountings if failed.
4. Symptom - Suspension Knock.
POSSIBLE CAUSE
REMEDY
1. Loose or worn suspension
component mountings and
fixings.
1. Check, tighten or renew relevant components and fixings.
