Engine compartment component locations

Make

Mini

Model

Mini Workshop Manual

Year

1996–2000

Section

Description and operation › Engine compartment component locations

Engine management system - MEMSEngine compartment component locations

ENGINE COMPARTMENT COMPONENT LOCATIONS

1. Engine Control Module (ECM)
2. Relay module
3. Idle Air Control Valve (IACV)
4. Fuel pressure regulator
5. Throttle Position (TP) sensor
6. Air cleaner
7. Manifold Absolute Pressure (MAP) sensor
8. Intake Air Temperature (IAT) sensor
9. Evaporative emission canister purge valve
10. Camshaft Position (CMP) sensor
11. Engine Coolant Temperature (ECT) sensor
12. Ignition coil
13. Heated Oxygen Sensor (HO2S)
14. Crankshaft Position (CKP) sensor
