SEAT Leon Mk101 · Power transmission
01 · Transmission

7-speed dual clutch gearbox 0AM (Gearbox identification): Technical data

Make
SEAT
Model
Leon Mk1
Section
7-speed dual clutch gearbox 0AM › Technical data › Gearbox identification
Power transmissionGearbox identification
Gearbox identification
Allocation of gearbox code letters → Chapter.

7-speed dual clutch gearbox 0AM (Gearbox identification): Technical data – SEAT Leon Mk1
KHN  - Gearbox identification letters
01. 06.06  - Date of manufacture: 01.05.06
14  - Factory key
14 15  - Time
0026  - Running number
