Transmission Front Mount Replacement (Manual Transmission - F40-6)

Make

Vauxhall

Model

Astra J

Section

Manual Transmission - F40-6 › Repair Instructions › Transmission Front Mount Replacement

Transmission/TransaxleTransmission Front Mount Replacement

Transmission Front Mount Replacement Removal Procedure 1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle .            2. Remove the transmission front mount to suspension frame bolt (4).            3. Remove the 2 transmission front mount to transmission bolts (1). 4. Remove the transmission front mount (2). Installation Procedure            1. Install the transmission front mount (2). Caution: Refer to Fastener Caution . 2. Install the 2 transmission front mount to transmission bolts (1) and tighten to 100 N·m (74 lb ft) .            3. Install the transmission front mount to suspension frame bolt (4) and tighten to 100 N·m (74 lb ft) . 4. Lower the vehicle.
