Dipped headlamps - wiring diagram
- Make
- Alfa Romeo
- Model
- GT Factory Service Manual
- Year
- 2003–2010
- Section
- Interior lighting › Dipped headlamps - wiring diagram
Wiring diagrams and electrical functionsDipped headlamps - wiring diagram
DIPPED HEADLAMPS - WIRING DIAGRAM
Wiring diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | JUNCTION UNIT | |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B5 | MAXI FUSE-1 BOX | |
| B99 | MAXIFUSE BOX ON BATTERY | Op. 5530B BATTERY AND LEADS |
| C10 | FRONT LEFT EARTH ( FRONT ) | |
| C11 | RIGHT FRONT EARTH ( FRONT ) | |
| C15 | FACIA EARTH, DRIVER''S SIDE | |
| F10 | LEFT HEADLAMP ( FRONT ) | Op. 5540B HEADLAMPS |
| F11 | RIGHT HEADLAMP | Op. 5540B HEADLAMPS |
| H1 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| H5 | STEERING COLUMN SWITCH UNIT | Op. 5550A STALK UNIT |
| M1 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
Wiring diagram
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B1 | JUNCTION UNIT | |
| B2 | JUNCTION UNIT UNDER DASHBOARD | Op. 5505A MULTI-FUNCTION COMPONENTS |
| B5 | MAXI FUSE-1 BOX | |
| B99 | MAXIFUSE BOX ON BATTERY | Op. 5530B BATTERY AND LEADS |
| C10 | FRONT LEFT EARTH ( FRONT ) | |
| C11 | RIGHT FRONT EARTH ( FRONT ) | |
| C15 | FACIA EARTH, DRIVER''S SIDE | |
| F10 | LEFT HEADLAMP ( FRONT ) | Op. 5540B HEADLAMPS |
| F11 | RIGHT HEADLAMP | Op. 5540B HEADLAMPS |
| H1 | IGNITION SWITCH | Op. 5520A IGNITION SWITCH |
| H5 | STEERING COLUMN SWITCH UNIT | Op. 5550A STALK UNIT |
| M1 | BODY COMPUTER | Op. 5505A MULTI-FUNCTION COMPONENTS |
