INSTRUMENT LIGHTING - WIRING DIAGRAM

Wiring diagram

Components

Component code	Name	Assembly reference
B1	JUNCTION UNIT
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
B5	MAXI FUSE-1 BOX
B99	MAXIFUSE BOX ON BATTERY	Op. 5530B BATTERY AND LEADS
C15	FACIA EARTH, DRIVER''S SIDE
C38	EARTH ON TUNNEL
D20	REAR DASHBOARD COUPLING ( REAR )
D31	RIGHT FRONT DOOR REAR COUPLING/.
D43	DASHBOARD/CENTRE CONSOLE COUPLING
D75	RADIO PHONE JUNCTION ( FACIA )
D97	SHORT CIRCUITING COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H1	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
H10	CONTROLS FOR HEADLAMP ALIGNMENT INSTRUMENT LIGHTING ADJUSTMENT ( FACIA )	Op. 5560B ANALOGUE CONTROL PANEL
H12	HAZARD WARNING LIGHTS, FOG LIGHTS, REAR FOG LAMPS CONTROL	Op. 5505A MULTI-FUNCTION COMPONENTS
H35	SWITCHES ON TUNNEL ( CONNECTORS )	Op. 7040L CABIN FLOOR COVERING
H50	ELECTRIC WINDOW SWITCH ON FRONT DOOR PASSENGER SIDE	Op. 7005M FRONT ELECTRIC WINDOWS
M1	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
P20	RADIO	Op. 5570T CAR RADIO AND CAR TELEPHONE
P20	RADIO	Op. 5580P CONNECT PANEL
P50	CIGARETTE LIGHTER/POWER SOCKET ( CONNECTORS )	Op. 7065C ACCESSORIES AND DECORATIONS
