ABS - LOCATION OF COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Location of components

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C12	ABS front earth
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
I30	Brake pedal switch
I30	Brake pedal switch	Op. 5550D BRAKE AND REVERSING LIGHTS
K70	Left front wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K71	Right front wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K75	Left rear wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K76	Right rear wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M50	ABS control unit	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Location of components

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C12	ABS front earth
C15	Facia earth, driver''s side
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
I30	Brake pedal switch
I30	Brake pedal switch	Op. 5550D BRAKE AND REVERSING LIGHTS
K70	Left front wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K71	Right front wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K75	Left rear wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
K76	Right rear wheel sensor for ABS	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M50	ABS control unit	Op. 3340A ABS CHECK/ADJUSTMENT DEVICES
