19 · Electrical

Code - wiring diagram

Wiring diagrams and electrical functionsCode - wiring diagram

CODE - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.2 8v · from 12/03

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.6 16v · from 12/03 · BIPOWER

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.3 JTD 16V · from 12/03

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.9 JTD 8V, 1.9 DIESEL · from 12/03

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.9 JTD 8V · from 12/03 · MY 2005

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
D004	FRONT/ENGINE COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT ECU	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
P91	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE

1.3 JTD 16V · from 12/03 · MY 2005

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
D004	FRONT/ENGINE COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT ECU	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
P91	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE

1.4 8v · from 12/03 · MY 2005

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
D004	FRONT/ENGINE COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE

1.6 16v · from 12/03 · BIPOWER, MY 2005

Component code	Description	Reference to the assembly
B001	JUNCTION UNIT	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	JUNCTION UNIT UNDER DASHBOARD	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	DASHBOARD EARTH, DRIVER''S SIDE
D004	FRONT/ENGINE COUPLING
E50	INSTRUMENT PANEL	Op. 5560B ANALOGUE CONTROL PANEL
H001	IGNITION SWITCH	Op. 5520A IGNITION SWITCH
M001	BODY COMPUTER	Op. 5505A MULTI-FUNCTION COMPONENTS
M010	ENGINE MANAGEMENT ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	AERIAL FOR FIAT-CODE	Op. 5580E ANTI-THEFT DEVICE
