CODE - LOCATION OF COMPONENTS

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Location of components

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.2 8v · from 12/03

Location of components

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE

1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Location of components

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
D4	Front/engine coupling
D4	Front/engine coupling	Op. 1060G DIESEL INJECTION PRESSURE PUMP ELECTRONIC CONTROL
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M10	Engine management ECU	Op. 1056B MULTI-POINT INJECTION SYSTEM (MPI)
P91	Aerial for Fiat-CODE	Op. 5580E ANTI-THEFT DEVICE
