Airbag - wiring diagram

Make

Fiat

Model

Doblò Factory Service Manual

Year

2000–2010

Section

Vehicle electronic systems › Airbag - wiring diagram

Wiring diagrams and electrical functionsAirbag - wiring diagram

AIRBAG - WIRING DIAGRAM

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 10/2000, up to 10/2000

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C50	Air Bag earth
C53	Side Bag + Head Bag earth
D58	Right Head Bag coupling
D59	Left Head Bag coupling
D62	Driver''s Side Bag/rear coupling
D62	Driver''s Side Bag/rear coupling	Op. 7045A FRONT SEAT ASSEMBLY
D63	Rear passenger Side- Bag coupling/
D63	Rear passenger Side- Bag coupling/	Op. 7045A FRONT SEAT ASSEMBLY
D69	Seat bridges/rear coupling
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
H75	Passenger''s Air Bag disablement switch	Op. 5580C AIR BAG SYSTEM
K66	Sensor for driver''s, Side Bag	Op. 5580C AIR BAG SYSTEM
K67	Passenger, Side Bag sensor	Op. 5580C AIR BAG SYSTEM
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M60	Air Bag control unit	Op. 5580C AIR BAG SYSTEM
Q9	Driver''s Air Bag	Op. 5580C AIR BAG SYSTEM
Q10	Clock spring on steering wheel	Op. 5580C AIR BAG SYSTEM
Q11	Air Bag in dashboard (passenger side)	Op. 5580C AIR BAG SYSTEM
Q20	Driver''s seat belt pre-tensioner	Op. 7065A FRONT SAFETY BELTS
Q21	Front passenger seat belt pre-tensioner
Q30	Driver''s Side Bag	Op. 5580C AIR BAG SYSTEM
Q31	Passenger Side Bag	Op. 5580C AIR BAG SYSTEM
Q40	Driver''s Head Bag
Q41	Passenger Head Bag

1.2 8v, 1.6 16v, 1.3 JTD 16V, 1.9 JTD 8V, 1.9 DIESEL · from 12/03

Wiring diagram

COMPONENTS

Component code	Name	Assembly reference
B1	Engine compartment junction unit
B1	Engine compartment junction unit	Op. 1004B POWER UNIT ASSEMBLY
B1	Engine compartment junction unit	Op. 5505A MULTI-FUNCTION COMPONENTS
B2	Junction unit under dashboard	Op. 5505A MULTI-FUNCTION COMPONENTS
C15	Facia earth, driver''s side
C50	Air Bag earth
C53	Side Bag + Head Bag earth
D58	Right Head Bag coupling
D59	Left Head Bag coupling
D62	Driver''s Side Bag/rear coupling
D62	Driver''s Side Bag/rear coupling	Op. 7045A FRONT SEAT ASSEMBLY
D63	Rear passenger Side- Bag coupling/
D63	Rear passenger Side- Bag coupling/	Op. 7045A FRONT SEAT ASSEMBLY
D69	Seat bridges/rear coupling
E50	Instrument panel
E50	Instrument panel	Op. 5560B ANALOGUE CONTROL PANEL
H75	Passenger''s Air Bag disablement switch	Op. 5580C AIR BAG SYSTEM
K66	Sensor for driver''s, Side Bag	Op. 5580C AIR BAG SYSTEM
K67	Passenger, Side Bag sensor	Op. 5580C AIR BAG SYSTEM
M1	Body computer	Op. 5505A MULTI-FUNCTION COMPONENTS
M60	Air Bag control unit	Op. 5580C AIR BAG SYSTEM
Q9	Driver''s Air Bag	Op. 5580C AIR BAG SYSTEM
Q10	Clock spring on steering wheel	Op. 5580C AIR BAG SYSTEM
Q11	Air Bag in dashboard (passenger side)	Op. 5580C AIR BAG SYSTEM
Q20	Driver''s seat belt pre-tensioner	Op. 7065A FRONT SAFETY BELTS
Q21	Front passenger seat belt pre-tensioner
Q30	Driver''s Side Bag	Op. 5580C AIR BAG SYSTEM
Q31	Passenger Side Bag	Op. 5580C AIR BAG SYSTEM
Q40	Driver''s Head Bag
Q41	Passenger Head Bag
