Fiat Scudo Factory Service Manual (1996-2006)06 · 55 Electrical equipment
06 · Electrical

Control units (page 2 of 3)

Make
Fiat
Model
Scudo Factory Service Manual
Year
1996–2006
Section
Control units (99 update)
55 Electrical equipmentControl units · page 2 of 3

Control units (page 2 of 3) – diagram from the 55 Electrical equipment chapter of the Fiat Scudo Factory Service Manual (1996-2006) factory manual.

Schematic wiring diagram of the BF00 junction unit showing multiple connector blocks (V 13U, L 13U, G 9U, R 13U, H 13U, C 13U, H1 3U) with internal routing and wire identifiers.

Copyright Fiat Auto

XII-99 - Cancels and replaces
