P55 Heated rear windscreen
- Make
- Fiat
- Model
- Stilo Factory Service Manual
- Year
- 2001–2007
- Section
- Various consumers › P55 Heated rear windscreen
Connectors and pin-outsP55 Heated rear windscreen
P55 Heated rear windscreen
P55A – Rear
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | N | C30 | 15 | |
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | N | C30 | 15 | |
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | N | C30 | 15 | |
P55B – Rear
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | MB | B2D | 15 | |
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | MB | B2D | 15 | |
| Wiring | Colour |
|---|---|
| 25 REAR | NERO |
| Pin | Cable | Destination | |||
|---|---|---|---|---|---|
| Sec. | Colour | Node | Connect. | Pin | |
| 1 | 2,5 | MB | B2D | 15 | |
