P30 Left rear speaker

Make

Fiat

Model

Stilo Factory Service Manual

Year

2001–2007

Section

Various consumers › P30 Left rear speaker

Connectors and pin-outsP30 Left rear speaker

P30 Left rear speaker

Wiring	Colour
34 REAR LEFT DOOR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	BN	1,5		D97M	2
2	NL	1,5		D97M	5

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	BN	1,5		D41	3
2	NL	1,5		D41	4

Wiring	Colour
25 REAR	NERO

Pin	Cable		Destination
	Sec.	Colour	Node	Connect.	Pin
1	BN	1,5		D68B	3
2	NL	1,5		D68B	4
