Instrument panel location components
- Make
- Fiat
- Model
- Ulysse Factory Service Manual
- Year
- 2002–2010
- Section
- Instrument panel › Instrument panel location components
Wiring diagrams and electrical functionsInstrument panel location components
INSTRUMENT PANEL LOCATION COMPONENTS
Location Components
Components
| Component code | Description | Reference to the assembly |
|---|---|---|
| B001 | Engine compartment junction unit | 5505A |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C020 | Passenger dashboard earth | |
| D001 | Front/dashboard coupling | |
| D070 | Driver''s seat coupling | |
| D213 | Fuel tank coupling | |
| E050 | Instrument panel | 5560B |
| I040 | Handbrake applied switch | 5550D |
| I046 | Driver''s seat belt switch | |
| K020 | Left brake pad wear sensor (switch) | 3310A |
| K021 | Right brake pad wear sensor (switch) | 3310A |
| K025 | Brake fluid level sensor (switch) | |
| K026 | Engine coolant level sensor | |
| K030 | Engine oil pressure switch | 1084A |
| K032 | Engine oil level sensor | 1084A |
| K036 | Engine coolant temperature sensor/sender unit | 1056B |
| M001 | Body computer | 5505A |
| M010 | Engine management control unit | 1060G |
| M060 | Air Bag control unit | 5580C |
| M140 | Warning lights and milometer control unit (NSO) | |
| M172 | Multifunction screen node | |
| N040 | Fuel pump | 1040A |
